Description

12″

2,700W max

1,500W RMS

Blue, cast aluminum basket with diamond-cut accents

Chrome back plate

2.5″ dual 4ohm voice coils

Overcompensating motor structure for increased magnetic strength

12mm T-yoke and top plate improve low-frequency dynamics

Vented T-yoke and frame reduces voice-coil heat buildup

Die-cast aluminum heat sink dust cap absorbs voice-coil heat

Aluminum dust cap fins dissipate heat and strengthen cone

Nonmagnetic nonresonant die-cast aluminum frame

2.5″ 4-layer voice coils with large gauge wire increases power

High-temperature-tolerant adhesives resist thermal failure

Nickel-plated, 8-gauge, spring-loaded compression wire terminals

Nontransfer spruce pulp cone and high-density polyether foam surround with UV and chemical protection

Dual poly-cotton suspension dampens violent accelerations

Stitched voice coil leads prevent potential damage

Efficiency: 85.4 @ 1W/1m

Motor volume: 373oz

Mounting depth: 6.875″

Optimum sealed enclosure: 1 cu ft

Optimum ported enclosure: 2 cu ft

Includes 1-piece gasket/trim ring with concealed mounting holes
