Description

Class AB

Marine grade, conformal-coated PC boards to resist corrosion from salt spray and moisture

ABYC and ASTM certified

Life Shield badge indicates testing against the elements

Q-Stasis preamp keeps incoming noise from source units at nearly immeasurablelevels, improving quality

Class SQ and Class Q1 circuitry–the same found in high-end mobile audio units

Built-in equalization with variable frequency adjustment

FLUID-FETS technology efficiently produces power and mimic the sound quality of the highest-end home amps

Voltage gain: .2V-6V

Signal-to-noise ratio: >93dB

Freq resp: 10Hz-45kHz

Crossover type: Electronic 12dB per octave

Tone control

Bass EQ: 0dB-9dB @ 45Hz

No 1ohm applications

Dim: 2.2″H x 17.01″W x 9.4″D

540W max

60W x 6 @ 4ohm

100W x 6 @ 2ohm

200W x 3 @ 4ohm bridged

Channels 1-6 crossover freq range: High pass 250Hz-4kHz Low pass 40Hz-250Hz
